Documentation

RACFHound mascot investigating a node graph

RACFHound is an end-to-end toolchain for mainframe RACF security analysis. It parses RACF database unloads, builds an access control graph, and exports it to BloodHound for attack path analysis.

Architecture

mfpandas          IRRDBU00 unload → DataFrames
    ↓
mfpandas-racfhound    DataFrames → OpenGraph (nodes + edges)
    ↓
racfhound         collect → transform → export pipeline

The three components are independently usable. mfpandas-racfhound can be embedded in your own tooling without the racfhound CLI.

Getting started

  1. Installation — pip install and dependencies
  2. Usage — CLI reference and pipeline options
  3. BloodHound Integration — API setup and saved queries

Graph model

RACFHound maps RACF constructs to typed BloodHound nodes:

Node kind Represents
RACFUser RACF user profile
RACFGroup RACF group profile
RACFDataset Dataset protection profile
RACFResource General resource (FACILITY, SURROGAT, …)
RACFPrivilege Named privilege: SPECIAL, OPERATIONS, AUDITOR, …
RACFStartedTask Started task (STARTED class, STDATA segment)

Edges encode access relationships: RACFMemberOf, RACFCanRead, RACFCanWrite, RACFHasPrivilege, RACFSurrogateFor, and more.
