BloodHound Integration

RACFHound mascot tracing an attack path through a graph

How it works

RACFHound uploads the RACF graph to BloodHound via the OpenGraph API. Once ingested, you can run Cypher queries and visualize attack paths in the BloodHound UI exactly as you would for Active Directory or Azure.

Saved queries

RACFHound ships with a set of pre-built Cypher queries. Install them:

racfhound query install \
  --url https://your-bloodhound-host \
  --token YOUR_API_TOKEN

APF write → SPECIAL

Find users who can write to an APF library — a path to supervisor state and full system compromise.

MATCH p=(u:RACFUser)-[:RACFCanWrite]->(d:RACFDataset {isAPF: true})
RETURN p

Surrogate chain to SPECIAL

Find users who can submit jobs as a SPECIAL user (directly or transitively).

MATCH p=(u:RACFUser)-[:RACFSurrogateFor*1..5]->(v:RACFUser)
         -[:RACFHasPrivilege]->(:RACFPrivilege {name: 'SPECIAL'})
RETURN p

Group JOIN → APF write

Find users whose group JOIN authority transitively grants write to an APF library.

MATCH p=(u:RACFUser)-[:RACFGroupAuth_JOIN]->(g:RACFGroup)
         -[:RACFCanWrite]->(d:RACFDataset {isAPF: true})
RETURN p

World-writable APF (UACC misconfiguration)

Datasets that any user can write to because UACC is too permissive.

MATCH p=(:RACFUser {name: 'PUBLIC'})-[:RACFCanWrite]->(d:RACFDataset {isAPF: true})
RETURN p

PROCLIB write → TRUSTED started task

Users who can write to a PROCLIB that runs a TRUSTED or PRIVILEGED started task.

MATCH (u:RACFUser)-[:RACFCanWrite]->(d:RACFDataset {isPROCLIB: true})
MATCH (t:RACFStartedTask)-[:RACFHasPrivilege]->(:RACFPrivilege {name: 'TRUSTED'})
RETURN u, d, t

Group-scoped SPECIAL

Users with SPECIAL authority scoped to a subtree of the group hierarchy.

MATCH p=(u:RACFUser)-[:RACFGroupScopeSpecial]->(g:RACFGroup)
RETURN p

Node properties reference

Property	Nodes	Description
`name`	all	Profile name / identifier
`isAPF`	`RACFDataset`	Dataset is in an APF library
`isPROCLIB`	`RACFDataset`	Dataset is in a PROCLIB concatenation
`isRevoked`	`RACFUser`	User account is revoked
`isProtected`	`RACFUser`	NOPWD=PRO; no password set (started task identity)
`hasSpecial`	`RACFUser`	RACF SPECIAL attribute
`hasOperations`	`RACFUser`	RACF OPERATIONS attribute
`hasAuditor`	`RACFUser`	RACF AUDITOR attribute
